Horizontal Stretch Wrapping Machine

Get a Price/Quote

Product Details:

Product Type Horizontal Stretch Wrapping Machine
Material Mild Steel
Capacity 10-40 Packs Per Hour
Computerized No
Automatic Grade Automatic
Voltage 220-240 V
Power 1.2 kW
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Horizontal Stretch Wrapping Machine Price And Quantity

Horizontal Stretch Wrapping Machine Product Specifications

Shift Speed 0.3 ~ 3 m/min (Adjustable)
Color Blue & Silver
Automatic Grade Automatic
Weight (kg) Approximately 850 kg
Overlap Scope 30-70% (Adjustable)
Voltage 220-240 V
Capacity 10-40 Packs Per Hour
Product Type Horizontal Stretch Wrapping Machine
Power 1.2 kW
Computerized No
Rotating Speed 20-90 RPM
Conveyer Length 2.2 meters
Material Mild Steel
Dimension (L*W*H) 3000 x 1450 x 1800 mm

Product Description

Entrust the quality of horizontal stretch wrapping machine manufactured by us. We are making this machine, specially for heavy loads. In this scenario, a high amount of wrap force is required. This machine is known for reducing the material cost as well as minimizing the damage. Provided with a rotating ring of diameter starting from 1300 mm, it has 160 rpm as the rotation speed of the ring. This version of the wrapping machine is ideal for packaging for products that are categorized under bulky and non-palatalized such as assembled furniture, doors, panels, pipes and windows. In other words, this machine is used to wrap irregular products. Its belt width is 220 mm and fixed-height belt is of 800 mm.

Horizontal Stretch Wrapping Machine Specifications:

ORBIT 4 Horizontal orbital automatic wrapping machine
Machine Characteristics
Ring rotation speed:	160rpm
Belt driven ring rotation	STD
Spool holder with frictioned roller	STD
Pneumatic cold clamping/cutting unit	STD
Power infeed and outfeed conveyor belts: L=600 mm	STD
Belt width:	220 mm
Fixed-height belt	800 mm
Infeed and outfeed side guides	OPT
Infeed and outfeed pressors Roller diameter: 44 mm Roller length: 240 mm	STD
Variable conveyor speed	817 m/1
Compressed air consumption:	3.5 NL/cycle
Power supply voltage:	400 V. 3Ph +N- 50/60 Hz
Installed power:	0.9 KW
Film spool characteristics
Max. external diameter (D):	200 mm
Film spool height (h):	50-125 mm
Film thickness:	17-50 m
Internal diameter (d):	76 mm

Optimal Wrapping Efficiency and Control

Employing an advanced powered pre-stretch film carriage and a PLC-controlled touch panel interface, the machine streamlines packaging automation. Its adjustable rotating and shift speeds accommodate a range of product dimensions, increasing efficiency and adaptability on the production floor.

Awareness and Application Safety

Safety remains a top priority with equipped features such as emergency stop and overload protection. The sturdy mild steel build and carefully engineered conveyor system safeguard both the operator and the machinery, supporting reliable use within a 5C to 40C operating range.

Versatile Product Handling Capabilities

Specially designed for aluminium, timber, and panel packaging, the device wraps a variety of long or irregular profiles with consistent overlap and tight sealing. It can efficiently package between 10 and 40 packs per hour, benefiting high-volume operations.

FAQs of Horizontal Stretch Wrapping Machine:

Q: How does the powered pre-stretch film carriage improve wrapping efficiency?

A: The powered pre-stretch film carriage stretches the film before it is applied to the product, reducing material consumption and providing a consistently tight wrap. This not only secures the product better but also lowers overall film usage, improving cost efficiency.

Q: What products can be wrapped with this machine?

A: This horizontal stretch wrapping machine is suitable for long or irregular shaped items such as aluminium profiles, tubes, timber, and panels. Its adjustable wrapping width and flexible conveyor make it ideal for diverse industrial packaging needs.

Q: When should I use the emergency stop and what happens?

A: The emergency stop should be engaged immediately if theres a safety hazard or equipment malfunction during operation. Once activated, the machine halts all movement, ensuring the protection of both the operator and the product until the issue is resolved.

Q: Where is this machine primarily used?

A: The machine is widely used in manufacturing environments, particularly in industries handling aluminium, timber, tubes, or similar long products. Its robust design is suited for warehouses and factories throughout India.

Q: What are the key steps in the wrapping process?

A: Products are placed on the motorized roller conveyor, then the PLC-controlled system manages the pre-stretch film application as the rollers move the item through. Film overlap, rotating speed, and shift speed are all adjustable to optimize the wrapping for the specific product dimensions.

Q: How does the PLC touch panel enhance machine operation?

A: The PLC touch panel offers intuitive operation, enabling easy adjustment of parameters like wrapping width, overlap scope, and speed settings. This allows operators to tailor the wrapping process for each product type, optimizing both performance and efficiency.

Q: What benefits does automated packaging provide compared to manual wrapping?

A: Automated packaging with this machine ensures consistent wrapping quality, reduces labor demands, minimizes film waste through efficient pre-stretching, and increases throughput. This results in cost savings and enhanced product protection during storage or transport.
